Description
Features
- 20 Speed
- Alloy frame with carbon forke
- Tiagra drivetrain
- Avid BB5R brakes
Specs
| Frame | Alloy 6061 Double Butted w/Disc Mounts and Internal Cable Routing, 1.5 Taper, Flat Mount Disc |
| Fork | Carbon Disc w/Alloy Steerer, 1.5 Taper |
| Headset | FSA Orbit C40-ACB, N.42/ACB, Angular Contact Bearings, 1-1/8"~1.5" Integrated Alloy Cap |
| Rims | Weinmann XC-180 Disc, Alloy Double Wall, 700c |
| Hubs (F/R) | Formula Alloy CX Disc QR, Cassette rear |
| Tires | Kenda Happy Medium, 700X35C, 120tpi Folding |
| Spokes | 14G Black, 32X32 w/Alloy Nipples |
| Derailleur, Front | Shimano New Tiagra, FD-4700, 31.8 Clamp |
| Derailleur, Rear | Shimano New Tiagra, RD-4700 |
| Shifters | Shimano New Tiagra, ST-4700 |
| Chain | KMC X10 w/Missing Link |
| Crankset | FSA New Omega, 4-Arm, 48/32, XS: 165, S: 170, M: 172.5, L-XL: 175 |
| BB | FSA Mega EXO Outboard Bearing |
| Cassette | Shimano CS-HG500, 11-32T, 10-Speed |
| Pedals | N/A |
| Seatpost | Q2 Carbon, 31.6x350mm |
| Saddle | KHS Sport Road |
| Handlebar | Alloy Butted Compact, 31.8, XS: 40cm, S-M: 42cm, L-XL: 44cm |
| Stem | Alloy 3D Forged, Threadless 4 Bolt, 31.8mm, XS: 80mm, S: 90mm, M-L: 100mm, XL: 110mm |
| Handlebar Tape | Cushion Tape |
| Brake Levers | Shimano Tiagra w/Tektro RL721 Shorty |
| Brakes | Avid BB5R, Road Mechanical Disc Brake w/160mm Rotors |
| Color | Matte Orange |
| Frame Size | XS/49, S/52, M/55, L/58 |
