Click here to view: HI200 75V High Current 200A ESC without water cooling enclosure

Spec:

• Voltage:14-75V( safe for 3-16S)
• Continuous Current : 200A
• Max Current :300A
• Supported sensors: ABI, HALL, AS5047,AS5048A
• EPRM:150000

Feature:

• Regenerative braking
• Sensored or sensorless operation + hybrid mode
• Configurable RPM-, current-, voltage- and power limits
• Input source: PPM, Analog, NRF Nyko Kama Nunchuck
• Communication ports: USB, CAN, UART
• Throttle curve and ramping for all input sources
• Seamless 4-quadrant operation
• Motor revolution, amp hour, watt hour counting
• Real time data analysis and read out via communication ports
• Adjustable protection against:
• Low input voltage
• High input voltage
• High motor current
• High input current
• High regenerative braking current (separate limits for the motor and the input)
• High RPM (separate limits for each direction)
• Digital VCC and analog VCC are produced by different voltage regulators respectively to make the system AD conversion more accurate
• Motor wire: 8AWG
• Power cable: 10AWG

Wiring Diagram With Water Cooling Enclosure:
