Features:

• The power supply tester is a robust voltage, tester for PC-power supply, ATX . BTX and ITX compliant, power supplies can be tested. LCD's indicate the status of voltage
• Plug power supply 24 PIN and P4 , P6 or P8 into the corresponding jack of the power test suite
• Power on the supply of power, will hear "DuDu" ring , if no flicker then the power supply output voltage is normal
• If a certain voltage signal was not detected, or the detected voltage value over the normal, will issue a "DuDu" long buzzer ;if the corresponding voltage value or PG flicker too, then the power is failed
• Suitable for the ambitious hobby user, as well as for a quick functional check in specialized trade

Specifications:
Product type: PC 20/24 Pin ITX ATX BTX LCD power supply tester
Interface Type: 20/24pin (ATX-connector)
Voltage Test: +12V, -12V, +5V, -5V, +3.3V, 5V Stand by (SB),12V Power Good
Connectors: floppy, HDD, CDROM, SATA, 4pin (P4), 8pin (Dual-CPU), 6pin (PCI-Express)
Material: Plastic & Electronics
Dimension: approx. 96 x 62 x 20mm
Color: Black
Net Weight: 63g

Package Included:
1 x LCD Power Supply Tester
