Description
The ZWmech Mechanical module includes a comprehensive range of mechanical utilities, symbols, fasteners, gears, material handling items (conveyor rolls, sprokets, Trajectory calculator..), springs, shafts utility and more!. Most modules draw in 2D or 3D.
ZWmech Mechanical works with all versions of ZWCAD.General Drafting Module
- Global Text manipulation:
- Style Changing: a powerful utility to change text from one style (or all styles) to another
- Text Find and Replace: searches for all instances of a nominated text and replaces it as specified
- Text Box: draws a box around selected text line or paragraph
- Width: changes the width factor of selected text
- Scale Globally: changes the height of text to a new height or scaled by a given factor
- Underline
- Layer control by pointing to an entity of desired layer:
- Locking
- Unlocking
- Changing
- Freezing
- Isolating: freeze entities on all layers except the entities on the layer selected
Specs
Installation Requirements
In order to work properly, your copy of ZWmech Mechanical requires:
|
