ZWmech Structural Pro is an integrated plug in for ZWCAD. The ZWmech Structural Steel Detailing utilities for the drawing of structural steel members. It includes steel shapes (beams, columns and miscelleneous), beam—connections, stairs, ladders, bracing, hand railing, frames, welding symbols, beam loading designer and much more. Steel shapes include: AISC, BHP, CISC, DIN, RSA, JIS, IS, Chinese. The module draws both in 2D & 3D and generates a weighted auto—BOM. Some modules include auto—dimensioning of compoments to fabrication details. ZWmech works with all versions of ZWCAD Structural Steel detailing is now ease using the Mech—Q Structural Detailing modules. The ZWmech Structural Steel design add—on is both customizable and easy to learn. The software supports both Metric && English (Imperial) Units.
Steel Shapes & Beams
Draws in both 2D & 3D and includes Auto—BOM with weighted BOM (fully customizable). This structural steel shape routine supports data listing with a pick & match option. Layers are fully customizable. Curved beam option also available. Annotates shapes and beams as needed.
- 2D & 3D Capability
- Auto—BOM with weighted BOM (fully customisable)
- Data listing, pick & match option
- Fully customisable layers
- Curved beam option
- Annotation option
Structural Stairs Utility
Structural Stairs Utility will draw stairs to the configuration set by the user. The routine will also draw Single—flight and multi—flight stairs in Front, Plan and End views and then add the main Dimensions and Stair Data as required. Handrail outline can also be included.
Structural Ladders Utility
The Ladder Utility will draw Side Stepping and Step Thru. ladders — Front, Plan and End views. The utility can also draw safety Cages and fabrication Detail. Auto Dimensioning is included.
Structural Hand Railing
- Customizable sizes, layers & shape
- Welded, "Monowills" and Square tube
- Steel or Aluminium
- 15 types of stanchion
- Optional "kick" plates
- Several draw options
- Easy to use and configure
- Several draw view options
Structural Bracing
Fully customizable sizes & layers. Supporting welded, welded cleat, bolted cleat or bolted straight bracing. Simple to use, draws bracing in 4 easy steps! Fixing options include Welded, welded cleat, bolted cleat or bolted straight.
Beam to Column Connections
Several connections types:
- Flexible: Angle seat
- Flexible: Bearing pad
- Flexible: End plate
- Flexible: Angle cleat
- Flexible: Web plate
- Rigid: Welded & erect cleat
- Rigid: Plate
- Plan or front draw views
- Customizable layers & connection sizes & design
- Auto—dimensioning to fabrication details
- Several draw options
- Easy to use and configure
Structural Welded Frames
- Bevel or Square corners
- Plan, End view (X) and End view (Y)
- Plan or end draw views
- Customizable layers & sizes
- Auto—dimensioning to fabrication details
- Several draw options
Beam Design Module
Calculate stresses and deflections for simple beam cases:
- Simply Supported
- Cantilever
- Propped Cantilever
- Build—in
- Several load cases and load combinations are supported Output:
- Reactions at supports
- Calculated Deflections and Stresses
- Plot of stress and deflections
- Printed Result
- Minimum Steel Sections for the given load cases
- Several configurations & calculation options
Welding Symbols
Several welding symbols Include:
- Fillet
- Bevel—butt
- Vee—Butt
- Square—Butt
- U—Butt
- J—Butt
- Flare—V
- Flare—bevel
- Plug
- Spot welding
- Seam welding
- Stud welding
- Bead welding
- Surface welding
- Welding note option
- Configurable size & layers
- Several options & auxiliary symbols: Site, all round, leader, intermittent.
Specs
Installation Requirements
In order to work properly, your copy of ZWmech Structural Pro requires:
|
